Display |
RoHs compliant. |
|
|
LCM model |
UNI-FHD133N011A |
|
|
Display Mode |
IPS，Normally Black |
|
|
Viewing Angle |
80 / 80 / 80 / 80 |
Typical |
|
Contrast ratio |
800:1 |
Typical |
|
NTSC |
72% |
Typical |
|
Resolution |
1920 RGB(H)×1080(V) |
Number of Dots (HxV) |
|
Pixel Pitch |
0.153 (H)*0.153 (V) |
mm (HxV) |
|
Active Area |
293.76(H)*165.24(V) |
mm (HxV) |
|
Outline Dimension |
307.6(H)×183.05(V)×5.4(T) |
mm (HxVxT) |
|
Display Interface |
2 Lane eDP 1.2 |
|
|
Brightness |
(Typical)800cd/m2 |
54LEDs(420mA/27V) |
|
Life Time(Backlight) |
LED 50K hrs. |
|
|
Operating temperature |
-30 ~ +80 |
℃ |
|
Storage temperature |
-30 ~ +80 |
℃ |
Important Note：
◎ If Purchaser intends to use this products for an application which requires higher level of reliability and/or safety in functionality and/or accuracy such as transport epuipment（e.g. medical，aircraft，train，automobile，etc.），disaster-prevention/security equipment or various safety equipment，Purchaser shall consult UNI DISPLAY on such use in advance.
◎ The system integrator of the prodcduct is responsible for compliance of the required approvals.
◎ Technical specification subject to change without prior notice.
◎ For further information,please refer to detailed specification of individual component.
If shall be mutuall conferred if nonconforming defect which result from unspecified cause in this specification arises
