型号 |
AMS465GC01 |
|
对角尺寸 |
4.65 英寸 |
|
类型 |
AMOLED |
|
解析度 |
720X1280 |
|
显示比例 |
9:16 |
|
横显/竖显 |
可选 |
|
显示尺寸 |
57.96X × 103.04mm (H×V) |
|
外观尺寸 |
63.2 × 112.3x1.8mm (H×V×D) |
|
显示亮度 |
180 -360cd/m² |
|
对比度 |
30000:1 (Typ.) |
|
响应时间 |
微秒级（us） |
|
工作温度 |
-40 ~ 80 °C |
|
存储温度 |
-45 ~ 85 °C |
|
工作电压 |
1.8/3.3/5.0V (Typ.)(VDD1/VDD2/ELVDD) |
|
接口类型 |
MIPI 4 LANE |
|
针脚 |
45 pins |
|
帧频率 |
60Hz |
|
触摸技术 |
电容式触摸屏 |
|
光源类型 |
自发光, 30K小时 |
|
支持颜色 |
16.7M |
|
Part number |
AMS465GC01 |
|
Size |
4.65 inch |
|
Panel type |
AMOLED |
|
Resolution |
720X1280(width X height) |
|
Aspect ratio |
9:16 |
|
Portrait/landscape |
Optional |
|
Active area size |
57.96(H)×103.04(V)X1.80(T) mm |
|
Outline size |
63.2(H)×112.3(V) mm |
|
Luminance |
180-360 cd/m² |
|
Contrast |
30000:1 |
|
Response time |
Microsecond class(us) |
|
Working temperature |
-40 ~ 80 °C |
|
Storage temperature |
-40 ~ 85 °C |
|
Working voltage |
3.3 V |
|
Interface type |
MIPI 4 LANE |
|
Pin numbers |
45pins |
|
Frame rate |
60 Hz |
|
Touch panel type |
On cell capacitive touch panel |
|
Backlight type |
Self-emitting light, 30K hours |
|
Color mode |
16.7M full color |
