型号 |
AMS397GS01 |
|
对角尺寸 |
3.97英寸 |
|
类型 |
AMOLED |
|
解析度 |
480X800 |
|
显示比例 |
3:5 |
|
横显/竖显 |
可选 |
|
显示尺寸 |
51.84 ×86.4 mm (H×V) |
|
外观尺寸 |
55.55 × 94.95 × 2.02mm (H×V×D) |
|
显示亮度 |
180-360 cd/m² |
|
对比度 |
20000:1 |
|
响应时间 |
微秒级(us) |
|
工作温度 |
-40 ~ 80 °C |
|
存储温度 |
-40 ~ 85 °C |
|
工作电压 |
3.7V |
|
接口类型 |
RGB |
|
针脚 |
61 pins |
|
帧频率 |
60Hz |
|
触摸技术 |
电容式触摸屏 |
|
光源类型 |
自发光, 30K小时 |
|
支持颜色 |
16.7M |
|
AMS397GS01 |
|
|
Size |
3.97 inch |
|
Panel type |
AMOLED |
|
Resolution |
480X800 |
|
Aspect ratio |
3:5 |
|
Active area size |
51.84 ×86.4 mm (H×V) |
|
Outline size |
55.85 × 94.95 × 2.02mm (H×V×D) |
|
Luminance |
180-360 cd/m² |
|
Contrast |
20000:1 |
|
Response time |
Microsecond class(us) |
|
Working temperature |
-40 ~ 80 °C |
|
Storage temperature |
-40 ~ 85 °C |
|
Working voltage |
3.7V |
|
Interface type |
RGB |
|
Drive IC |
S6E63M0 |
|
Pin numbers |
61pins |
|
Frame rate |
60 Hz |
|
Touch panel type |
On cell capacitive touch panel |
|
Backlight type |
Self-emitting light, 30K hours |
|
Color mode |
16.7M full color |
