型号 |
AMS353PD01 |
|
对角尺寸 |
3.53英寸 |
|
类型 |
AMOLED |
|
解析度 |
480X800 |
|
显示比例 |
3:5 |
|
横显/竖显 |
可选 |
|
显示尺寸 |
47.5(横)×76.8(竖) mm |
|
外观尺寸 |
50.4(横)×86.3(竖)X1.95 mm |
|
显示亮度 |
160-260 cd/m² |
|
对比度 |
10000:1 (Typ.) |
|
响应时间 |
微秒级（us） |
|
工作温度 |
-40 ~ 80 °C |
|
存储温度 |
-40 ~ 85 °C |
|
工作电压 |
3.7V |
|
接口类型 |
RGB |
|
驱动IC |
S6E63M0 |
|
针脚 |
61 pins |
|
帧频率 |
60Hz |
|
触摸技术 |
电容触摸屏 |
|
光源类型 |
自发光, 30K小时 |
|
支持颜色 |
16.7M |
|
Part number |
AMS353PD01 |
|
Size |
3.53 inch |
|
Panel type |
AMOLED |
|
Resolution |
480X800 |
|
Aspect ratio |
3:5 |
|
Portrait/landscape |
Optional |
|
Active area size |
47.5(H)×76.8(V) mm |
|
Outline size |
50.4(H)×86.3(V)X1.95 mm |
|
Luminance |
160-260 cd/m² |
|
Contrast |
10000:1 |
|
Response time |
Microsecond class(us) |
|
Working temperature |
-40 ~ 80 °C |
|
Storage temperature |
-40 ~ 85 °C |
|
Working voltage |
3.7V |
|
Interface type |
RGB |
|
Drive IC |
S6E63M0 |
|
Pin numbers |
61 pins |
|
Frame rate |
60 Hz |
|
Touch panel type |
On cell capacitive touch panel |
|
Backlight type |
Self-emitting light |
|
Color mode |
16.7M full color |
