型号 |
AMS369FG06 |
|
对角尺寸 |
3.69英寸 |
|
类型 |
AMOLED |
|
解析度 |
480X800 |
|
显示比例 |
3:5 |
|
横显/竖显 |
可选 |
|
显示尺寸 |
48.24(横)×80.4(竖) mm |
|
外观尺寸 |
53.94(横)×90(竖) X1.5mm |
|
显示亮度 |
180-300 cd/m² |
|
对比度 |
10000:1 (Typ.) |
|
响应时间 |
微秒级（us） |
|
工作温度 |
-40 ~ 80 °C |
|
存储温度 |
-40 ~ 85 °C |
|
工作电压 |
3.7V |
|
接口类型 |
RGB |
|
驱动IC |
TL2796 |
|
针脚 |
51 pins |
|
帧频率 |
60Hz |
|
触摸技术 |
无触摸屏 |
|
光源类型 |
自发光, 30K小时 |
|
支持颜色 |
16.7M |
|
Part number |
AMS369FG06 |
|
Size |
3.69 inch |
|
Panel type |
AMOLED |
|
Resolution |
480X800 |
|
Aspect ratio |
3:5 |
|
Portrait/landscape |
Optional |
|
Active area size |
48.24(H)×80.4(V) mm |
|
Outline size |
53.94(H)×90(V) X1.5mm |
|
Luminance |
170-300 cd/m² |
|
Contrast |
10000:1 |
|
Response time |
Microsecond class(us) |
|
Working temperature |
-40 ~ 80 °C |
|
Storage temperature |
-40 ~ 85 °C |
|
Working voltage |
3.7V |
|
Interface type |
RGB |
|
Drive IC |
TL2796 |
|
Pin numbers |
51pins |
|
Frame rate |
60 Hz |
|
Touch panel type |
Non touch panel |
|
Backlight type |
Self-emitting light, 30K hours |
|
Color mode |
16.7M full color |
