10.1寸1024*600 IPS TFT稳定量产，欢迎订购
| Screen Size | 10.1" | |
| Module Size(WxHxD,mm) | 235.3×143.0×4.5 | |
| Active Area(mm) | 222.72×125.28 | |
| Display Mode | Normally black | |
| Display colors | 16.7M | |
| Resolution | 1024 × 3(RGB) × 600 | |
| Viewing Angle (Tpy.)θT/θB/θL/θR | 85/85/85/85 | |
| Viewing direction | IPS | |
| Luminance(nits) | 500 | |
| Contrast Ratio | 800 | |
| Power Consumption (W) | 0.561 | |
| Interface | LVDS | |
| connecting type | 60pin connector | |
| Operation Temperature( ℃) | -20~70 | |
| Storage Temperature (℃) | -30~80 | |
| Backlight type | LED | |
| Response Time(ms) | 25 | |
| Dot Pitch(WxH,mm) | 0.2175 x 0.2088 | |
