| 型号/Model No: YS-CB-1010BM89-1602N/T/C |
★★★★★ |
||
|
触摸功能/Touch Panel |
无触摸 / Non-TP |
√ |
|
|
电阻触摸 / RTP |
√ |
||
|
电容触摸 / CTP |
√ |
||
| 参数 / Parameters |
备注 / Remarks |
||
|
外形尺寸 |
Outline Dimension |
265.00(W)×147.00(H)×9.28(T) |
mm |
|
AA区尺寸 |
Active Area |
222.72(W)×125.28(H) |
mm |
|
分辨率 |
Resolution |
1024×600 |
DOTS |
|
存储内存 |
Storage Memory |
16MB |
|
|
接口 |
Interface |
RS232(TTL) / RS232(COM) |
|
|
视角 |
Viewing Angle |
IPS |
|
|
亮度 |
Brightness |
500CD/m2 |
|
|
工作电压 |
Operating Voltage |
5.0V |
|
|
温度 |
Operating temperature |
-20~70 ℃ |
|
|
Storage temperature |
-30~80 ℃ |
||
