( ) Preliminary Specifications
(V) Final Specifications
Module 11.6”(11.57”) HD 16:9 Color TFT-LCD
with LED Backlight design
Model Name B116XTN02.3 (H/W:0A)
Note ( )
LED Backlight with driving circuit design
Customer Date
Checked &
Approved by
Date
Note: This Specification is subject to change
without notice.
Approved by Date
Luke Lin 12/06/2013
Prepared by Date
HuiWen Huang 12/18/2013
NBBU Marketing Division
AU Optronics corporation
2 of 31
AU OPTRONICS CORPORATION
Product Specification
B116XTN02 V3 Document Version : .01
Contents
1. Handling Precautions .............................................................. 4
2. General Description ................................................................ 5
2.1 General Specification ..........................................................................................................................5
2.2 Optical Characteristics ........................................................................................................................6
3. Functional Block Diagram ..................................................... 11
4. Absolute Maximum Ratings................................................... 13
4.1 Absolute Ratings of TFT LCD Module.............................................................................................13
4.2 Absolute Ratings of Environment .....................................................................................................13
5. Electrical Characteristics....................................................... 14
5.1 TFT LCD Module..............................................................................................................................14
5.2 Backlight Unit ...................................................................................................................................17
6. Signal Interface Characteristic.............................................. 18
6.1 Pixel Format Image ...........................................................................................................................18
6.2 Integration Interface Requirement.....................................................................................................19
6.3 Interface Timing ................................................................................................................................20
6.4 Power ON/OFF Sequence .................................................................................................................21
7. Panel Reliability Test ............................................................ 24
7.1 Vibration Test ....................................................................................................................................24
7.2 Shock Test .........................................................................................................................................24
7.3 Reliability Test...................................................................................................................................24
8. Mechanical Characteristics.................................................... 25
8.1 LCM Outline Dimension...................................................................................................................25
9. Shipping and Package ........................................................... 28
9.1 Shipping Label Format......................................................................................................................28
9.2 Carton Package..................................................................................................................................29
9.3 Shipping Package of Palletizing Sequence........................................................................................30
10. Appendix: EDID Description ................................................ 31
3 of 31
AU OPTRONICS CORPORATION
Product Specification
B116XTN02 V3 Document Version : .01
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2013/12/06 All First Edition for Customer
0.2 2013/12/18 P.25 LCM O.D 158.5 LCM O.D 157.5
4 of 31
AU OPTRONICS CORPORATION
Product Specification
B116XTN02 V3 Document Version : .01
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure
human earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be
damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The
LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Disconnecting power supply before handling LCD modules, it can prevent electric shock, DO
NOT TOUCH the electrode parts, cables, connectors and LED circuit part of TFT module
that a LED light bar build in as a light source of back light unit. It can prevent electrostatic
breakdown.
5 of 31
AU OPTRONICS CORPORATION
Product Specification
B116XTN02 V3 Document Version : .01
2. General Description
B116XTN02.3 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel, a
driver circuit, and LED backlight system. The screen format is intended to support the 16:9 HD,
1366(H) x768(V) screen and 262k colors (RGB 6-bits data driver) with LED backlight driving
circuit. All input signals are eDP interface compatible.
B116XTN02.3 is designed for a display unit of notebook style personal computer and industrial
machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 ℃ condition:
Items Unit Specifications
Screen Diagonal [mm] 293.8
Active Area [mm] 256.125 X 144.0
Pixels H x V 1366x3(RGB) x 768
Pixel Pitch [mm] 0.1875 x 0.1875
Pixel Format R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance (ILED=20mA)
(Note: ILED is LED current)
[cd/m
2
] 220 typ. (5 points average)
Luminance Uniformity 1.6 max. (13 points)
Contrast Ratio 400 typ
Response Time [ms] 8 typ
Nominal Input Voltage VDD [Volt] +3.3 typ.
Power Consumption [Watt] 2.65
Weight [Grams] 220 max.
Min. Typ. Max.
Length 277.5 278 278.5
Width 167.5 168 168.5
Physical Size
Include bracket
[mm]
Thickness - - 3.0
Electrical Interface 1 lane eDP
Glass Thickness [mm] 0.4
6 of 31
AU OPTRONICS CORPORATION
Product Specification
B116XTN02 V3 Document Version : .01
Surface Treatment Anti-Glare, Hardness 3H,
Support Color 262K colors ( RGB 6-bit )
Temperature Range
Operating
Storage (Non-Operating)
[
oC]
[
oC]
0 to +50
-20 to +60
RoHS Compliance RoHS Compliance
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25℃ (Room Temperature) :
Item Symbol Conditions Min. Typ. Max. Unit Note
White Luminance
ILED=20mA
5 points average
185 220 - cd/m
2
1, 4, 5.
θR
θL
Horizontal (Right)
CR = 10 (Left)
40
40
45
45
-
-
degree
Viewing Angle
ψH
ψL
Vertical (Upper)
CR = 10 (Lower)
10
30
15
35
-
-
4, 9
Luminance
Uniformity
δ5P 5 Points - - 1.25 1, 3, 4
Luminance
Uniformity
δ13P 13 Points - - 1.6 2, 3, 4
Contrast Ratio CR - 400 - 4, 6
Cross talk % 4 4, 7
Tr Rising -
-
Response Tf Falling - -
Time
TRT Rising + Falling - 8 16
msec 4, 8
Rx 0.537 0.567 0.597
Red
Ry 0.304 0.334 0.364
Gx 0.300 0.330 0.360
Green
Gy 0.539 0.569 0.599
Bx 0.125 0.155 0.185
Blue
By 0.106 0.136 0.166
Wx 0.283 0.313 0.343
Color /
Chromaticity
Coodinates
White Wy 0.299 0.329 0.359
NTSC %
CIE 1931
- 45 -
