TFT LCD Panel
Product Tags :Color TFT-LCD, IPS LCD
Application :Desktop Monitor
Panel Type :a-Si TFT-LCD
Panel Composition :LCM
Panel Size :21.5"
Resolution :1920×1080
Aspect Ratio :16:9 (W:H)
Form Factor :Flat Rectangle
Active Area :476.06 (W) × 267.79 (H) mm (A.A)
Outline Dimension :495.6 (W) × 292.2 (H) mm
Max. Depth :13.87mm
LC Family :IPS Family
Polarizer :Transmissive
Brightness :800(Typ.) with touch panel
Viewing Direction :Symmetry
Display Colors :16.7M
Backlight Type :WLED
Interface Type :LVDS
Interface Pins :30 Pins
Operating Temp. :0 ~ 50 °C
Product Tags :Color TFT-LCD, IPS LCD
Application :Desktop Monitor
Panel Type :a-Si TFT-LCD
Panel Composition :LCM
Panel Size :21.5"
Resolution :1920×1080
Aspect Ratio :16:9 (W:H)
Form Factor :Flat Rectangle
Active Area :476.06 (W) × 267.79 (H) mm (A.A)
Outline Dimension :495.6 (W) × 292.2 (H) mm
Max. Depth :13.87mm
LC Family :IPS Family
Polarizer :Transmissive
Brightness :800(Typ.) with touch panel
Viewing Direction :Symmetry
Display Colors :16.7M
Backlight Type :WLED
Interface Type :LVDS
Interface Pins :30 Pins
Operating Temp. :0 ~ 50 °C
Storage Temp. :-20 ~ 60 °C
