12.1" TFT LCD Panel / Customized Available
Product Tags :Color TFT LCD, Wide viewing LCD, IPS LCD,
Panel Type :IPS TFT-LCD
Panel Size :12.1"
Resolution :1280×800
Aspect Ratio :16:10(W:H)
Form Factor :Flat Rectangle
Active Area :261.12 (W) × 163.2 (H) mm (A.A)
Outline Dimension :294.1(W) × 196.2(H) mm
Max. Depth :8.7mm
LC Family :IPS
Polarizer : Transmissive
Brightness :450(Typ.)
Viewing Direction :Symmetry
Display Colors :16.7M
Backlight Type :WLED
Interface Type :LVDS
Interface Pins :40 Pins
Touch Panel :PCAP
Operating Temp. :-20 ~ 70 °C
Storage Temp. :-30 ~ 80 °C
