TFT-LCD Panel
Product Tags :Color TFT-LCD, IPS LCD, Capacitive Touch LCD
Panel Size :5"
Resolution :1024x600
Form Factor :Flat Rectangle
Active Area :154.21mm(W)*85.92mm(H)
Outline Dimension :182.07(W)*117.6(H)
Max. Depth :2.5 mm
LC Family :IPS
Polarizer :Transmissive
Brightness :300 (Typ.)
Contrast Ratio :450:1 (Typ.)
Viewing Angle :85/85/85/85 (L/R/U/D)
Viewing Direction :Free
Display Colors :16.7M
Color Arrangement: RGB
Backlight Type :WLED
Interface Type: RGB I/F
Interface Pins :50 Pins
Assembly Type: COG
Operating Temp. :-20 ~ 70 °C
Storage Temp. :-30 ~ 80 °C
